ICAO Type A Obstruction Light , High Intensity Aviation Obstruction Light FAA

Name: ICAO Type A Obstruction Light High Intensity Aviation Obstruction Light FAA
Brand: Annhumg
Price: 800.00 USD

ICAO Type A Obstruction Light , High Intensity Aviation Obstruction Light FAA Manufactures

Brand Name : Annhumg

Model Number : AH-MI-A2

Certification : FAA

Place of Origin : China

MOQ : 1

Price : $800.00 - $1,000.00

Payment Terms : L/C, T/T, Western Union, MoneyGram

Delivery Time : 3-15days

Packaging Details : Plastic bag with paper carton.

Product Weight（kg） : 3.5

Lamp Luminous Efficiency(lm/w) : 120

IP Rating : IP68

Lamp Body Material : Aluminum Alloy

Light Source : LED, CREE high intensity LED

Flash Characteristics : 20-60FPM - Type A (factory setting: 20FPM)

Contact Now

Product Description

ICAO Type A Obstruction Light , High Intensity Aviation Obstruction Light FAA

High-intensity Type A L856 Aviation Obstruction Light

●This High-intensity Aviation Obstruction Light flashing white color 24 hours and designed for marking top of obstacle that exceed 150 meters in height.
 ●Ultra high intensity CREE LED is used for the light source ensure light’s long life experience and good performance.
 ●Self-designed reflection board ensure less LED could emitting brighter light.

Specification

SPECIFICATIONS	AH-HI-A0 LED High-intensity Type A Aviation Obstruction Light
Light Characteristics
Light Source	CREE high intensity LED
Available Colors	White
Intensity(cd)	≥200,000cd(Daytime) (ICAO Type A)
	Optional: 270,000cd±25%(Daytime) (FAA L-856)
	≥20,000cd(Twilight)
	≥2,000cd(Night)
Horizontal Output(degrees)	90
Vertical Divergence(degrees)	3-7
Flash Characteristics	40-60FPM(40fpm as factory setting)
Operation Mode	24hours operation, 3 different modes
LED Life Experience(hours)	>100,000
Electrical Characteristics
Operating Voltage	DC(48VDC) or AC(110, 240V) or others
Average Power(W)	＜76W(40fpm)
Circuit Protection	Integrated
Physical Characteristics
Body Material	Polycarbonate
Base Material	Powder coated die-casting aluminum
Mounting	470×100×θ12
Dimension(mm)	508×186×236
Weight(kg)	10
Product Life Expectancy	10 years Plus
Environmental Factors
Humidity	0%-100%
Temperature(℃)	-55˚C ~ 70˚C
Wind Speed	80m/s
Waterproof	IP67
Compliance
ICAO	Annex 14 Volume 1,'Aerodrome Design and
	Operations’ Seventh edition 2016, table 6.3
	High-intensity Type A White Obstacle Light
FAA	L-856, L-857
Options Available
	NVG(Night Vision Goggles) compatible LED
	GPS Sync Flashing
	Dry Contact alarm(NO COM NC)
	User adjustable flashing rate (40, 50, 60)
	Solar power system

Packing & Delivery

Company Profile

Shenzhen Anhang Technology Company Limited is a high technology enterprise engaging in research, production, sales and after-sales services for a wide range of Aviation Obstruction Light,Aircraft Warning Light,Helipad Light, LED Marine Lanterns,LED Bulb and Aircraft Warning Sphere.We are a domestic market leader in the field of navigation lights and a supporter of green and safe emissions. Our products are widely used in Civil Airports, Helipads, Communication Towers, Factory,Power Plant Chimneys,Television Tower, Port, Bridges, and High-rise buildings, Buoyage in sea, etc. Website:www.annhung.com www.ahicao.com

FAQ

1.Can I have a sample order for obstruction light?
 Yes, we welcome sample order to test and check quality.

 2.What about the lead time?
 Sample needs 1-3 days, mass production needs 1-2 weeks for order quantity more than 100 units.

 3.Do you have any MOQ limit for aviation obstruction light order?
 Low MOQ, 1pc for sample checking is available.

 4.How do you ship the goods and how long does it take to arrive?
 We usually ship by DHL, UPS, FedEx or TNT. It normally takes 3-5 days to arrive. Airline and sea shipping also optional.

 5.How to proceed an order for obstruction light?
 Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly
 customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

 6.Is it ok to print my logo on led obstruction light product?
 Yes. Please inform us formally before our production and confirm the design firstly based on samples.

 7.Do you offer guarantee for the products?
 Yes, we offer 3-5 years warranty to our products.
