FAA obstruction lighting Low Intensity L810 Single Aviation Obstruction Light AH-LI-B2

Name: FAA obstruction lighting Low Intensity L810 Single Aviation Obstruction Light AHLIB2
Brand: Annhumg
Price: 50.00 USD

FAA obstruction lighting Low Intensity L810 Single Aviation Obstruction Light AH-LI-B2 Manufactures

Brand Name : Annhumg

Model Number : AH-LI-B2

Certification : FAA

Place of Origin : China

MOQ : 1

Price : $50.00 - $65.00

Supply Ability : 1000 Piece/Pieces per Month

Delivery Time : 3-15days

Packaging Details : 1piece in 1 carton

Light Source : LED

AIP Rating : IP68

OLamb Body Material : UV protected Polycarbonate

LED Life Experience(hours) : >100,000

Input Voltage(V) : DC(12V, 48VDC) or AC(110-240VAC) or others

Body Material : Body Material

Contact Now

Product Description

AH-LI-B2 Low-intensity L810 Single Aviation Obstruction Light

This Low-intensity light is a steady burning aviation obstruction light designed for marking top of obstacle that do not exceed 45 meters in height

Specification

SPECIFICATIONS	AH-LI-B2 Low-intensity L810 Single Aviation Obstruction Light
Light Characteristics
Light Source	LED
Available Colors	Red
Intensity(candela)	≥32.5cd(type B),others optional(10cd, 100cd,etc)
Horizontal Output(degrees)	360
Vertical Divergence(degrees)	≥10
Flash Characteristics	Steady-burning/20/30/60 adjustable
Operation Mode	Dusk-to-dawn Automatically as standard.
LED Life Experience(hours)	>100,000
Electrical Characteristics
Operating Voltage	DC(12V, 48VDC) or AC(110-240VAC) or others
Power(W)	2.5
Lightning surge	IEC61000-4-5 L- N ±3kV IEC61000-4-5 L- PE ±6kV IEC61000-4-5 N- PE ±6kV
Electrostatic	IEC61000-4-2 Contact discharge 8kV
Circuit Protection	Integrated
Physical Characteristics
Body Material	Polycarbonate
Base Material	Die-casting aluminum
Mounting	3/4 inch pipe thread as standard. 1inch as option
Dimension(mm)	Φ90×130
Weight(kg)	0.3
Product Life Expectancy	10 years Plus
Environmental Factors
Ambient Temperature(℃) -55℃~+70℃	-40~75
Storage temperature(℃)	-55~70
Humidity	10%-95%RH(No condensation)
Wind Speed	130m/s
Waterproof	IP66
Compliance
ICAO	Annex 14 Volume 1,'Aerodrome Design and
	Operations’ Seventh edition July 2016, table 6.3
	Low-intensity Type A/B/E Obstacle Light
FAA	L-810
Options Available
	Flashing rate
	NVG(Night Vision Goggles) compatible LED
	Dry contact alarm(NO COM NC)
	GPS sync flashing

FAA obstruction lighting Low Intensity L810 Single Aviation Obstruction Light AH-LI-B2

Packing & Delivery

Company Profile

Shenzhen Anhang Technology Company Limited is a high technology enterprise engaging in research, production, sales and after-sales services for a wide range of Aviation Obstruction Light,Aircraft Warning Light,Helipad Light, LED Marine Lanterns,LED Bulb and Aircraft Warning Sphere.We are a domestic market leader in the field of navigation lights and a supporter of green and safe emissions. Our products are widely used in Civil Airports, Helipads, Communication Towers, Factory,Power Plant Chimneys,Television Tower, Port, Bridges, and High-rise buildings, Buoyage in sea, etc. Website:www.annhung.com www.ahicao.com

FAQ

1.Can I have a sample order for obstruction light?
 Yes, we welcome sample order to test and check quality.

 2.What about the lead time?
 Sample needs 1-3 days, mass production needs 1-2 weeks for order quantity more than 100 units.

 3.Do you have any MOQ limit for aviation obstruction light order?
 Low MOQ, 1pc for sample checking is available.

 4.How do you ship the goods and how long does it take to arrive?
 We usually ship by DHL, UPS, FedEx or TNT. It normally takes 3-5 days to arrive. Airline and sea shipping also optional.

 5.How to proceed an order for obstruction light?
 Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly
 customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

 6.Is it ok to print my logo on led obstruction light product?
 Yes. Please inform us formally before our production and confirm the design firstly based on samples.

 7.Do you offer guarantee for the products?
 Yes, we offer 3-5 years warranty to our products.
